“The punches could not be sharp- ened due to the punch breakage,” recalls Steven Couture, Cowles manufacturing design engineer, noting that these types of punches, used to pierce holes, “are not conventionally restrained, but are taper- cut and then pressed into a holder.”
Problems occurred while stamping 0.157-in.-thick high-strength low-alloy steel (SAE-J1392 070XLF, 345-MPa yield strength) using the small, specially shaped punches with sharp corners.
Coating Success
“We suffered excessive premature punch failure,” says Pelkey. “Severe galling on the sides of the punches caused the punch ends to actually rip off as they would weld themselves into the material strip on the upstroke of the press. Over time (dating from the start of 2008) we tried various coatings with minimal or no success until we tried the FortiPhy Ultra Endurance chromium- nitride coating (from Phygen, Inc., Min- neapolis, MN).”
Unlike hot-processed chemical- vapor-deposition CVD and thermal- diffusion TD coatings, which combine with carbon molecules within the sub- strate to form a hard layer, the FortiPhy coating is applied to a surface using a special high-adhesion process. It does not require diffusion within the substrate to build a hard coating. Instead, the process applies a layer of nano-sized particles onto the surface and no carbon or other molecules are leached from the sub- strate. This means that every recoat of FortiPhy has the same toughness and lasts as long as the first. More impor- tantly, no decarburization or weakening of the substrate occurs. Also, because the coating is applied at a relatively low temperature—950 F—there is no dis- tortion or size change to tools, making it easier to assemble complex tooling.
from the physical vapor deposition (PVD) coating process, based on the principles of plasma acceleration and which results in high plasma density and an intense, low-energy ion bom- bardment during coating deposition.
Says Pelkey: “The coating allows us to produce an average of 16,000 stampings per run between sharpenings. And, we can resharpen the punches for contin- ued life, which we could not do before.”
Thanks to the improved punch per- formance, Cowles now can complete a full part run without shutting down the press to remove the tooling and replace broken punches. That’s a huge timesaver, according to Pelkey, because the complicated tooling requires lengthy setup time. Broken punches used to cause six or seven stoppages per run.
“The FortiPhy-coated punches last for the whole run without the need for resharpening,” Pelkey says. “Producing
“Essentially we would lose a week every time the punches broke. That does not happen now.”
a new punch consumes 9 hr. just on the wire-EDM machine, then a couple of days to send the punches out for coat- ing. Essentially we would lose a week every time the punches broke. That does not happen now.
“Now, if needed, we can resharpen the punches,” Pelkey continues, “which takes just a few hours. But again, the punches last through an entire run, so we don’t have to stop the press and resharpen. This saves our company hours of downtime and the expense of replacing punches.”
BetterToughness AddsCouture:“Thelubricityfromthe
and Hardness Increase Wear Resistance
Cowles’ engineers find that the For- tiPhy coating exhibits extreme hardness and toughness, brings high abrasive- wear resistance. These properties result
new coating has been spectacular. We no longer have problems with material catch- ing the punches and breaking them.” MF
Article supplied by Phygen, Inc., Min- neapolis, MN: tel. 888/749-4361, www.phygen.com.
