back and forth to a workstation two or three times a day,” says Wild.
Fixture Examples Abound
In one case, relays Wild, Solaxis Ingen- ious Manufacturing in Bromont, Canada, using Fortus 3D printers from Stratasys, designed and manufactured a jig for an automotive supplier, which uses it to assemble high-volume door compo- nents. After developing several iterations of the jig, Solaxis not only was able to produce a 3D-printed jig that is more than 100 lb. lighter than a typical jig for this application (the 3D-printed jig weighs 28 lb.), but it also slashed design and manufacturing time by at least two- thirds as compared with traditional methods, according to Solaxis officials.
“No longer is a crane operation needed nor another person needed to spot the jig,” says Wild, “so the burden rate of that tool is reduced.”
Another example: TS Tech, in sup- porting its stamping operations, switched to 3D printing to produce a
seat-bracket check tool. Stratasys Direct Manufacturing redesigned and pro- duced the tool, which featured a weight reduction from 40 to 4 lb. with a pro- duction-time reduction from six to two weeks. The new tool not only had a smaller profile, but it provided better part alignment and was easier to trans- port than the inspection tool it replaced. And, report TS Tech officials, it was tough enough to withstand the needed 42,000-inspections lifetime.
Oreck Manufacturing, according to Wild, is another convert to 3D printing, using the process to create custom assembly fixtures for its high-end com- mercial vacuum cleaners. According to Oreck’s senior model maker, the company has reduced fixture-produc- tion costs by 65 percent by using its inhouse FDM 3D printers. Oreck has used AM to make hundreds of inspec- tion fixtures for its CMMs. On average, it saves $200 and 6.5 days versus having them machined.
Before employing AM, Oreck took
30 days to complete its first-article inspections of 20 to 30 components for a new product. After receiving the first samples from production tooling, the QA department would start making fixtures and programming the coordi- nate measuring machine (CMM). On the 30th day, it would complete the CMM inspection and release the pro- gram to the production floor. With inhouse 3D printing, the company can quickly begin producing fixtures via its 3D printers and begin CMM pro- gramming when a tooling order is released, not after samples are received. As a result, the Quality Assurance department is ready and waiting for the arrival of the first samples. The company estimates that it can save $100,000 to $500,000 annually in such wait-time reductions.
Rapid Tool-Up for Metalforming
Nonmetal AM has proven successful not only as a method to manufacture
